DG350-3 Terminal Block 3-Pole 3.5mm - (AD7976)

Description:

3.5mm-pitch screw terminals. Comes in 2 or 3 positions and has the really cool feature of sliding locks to form any size you need (4 pins, 5, or up to 20 pins without issues). Rated up to 300V at 5A. The terminal can accept 26 to 18 AWG wires. The pin pitch is 3.5mm, these are thick enough pins (1.0mm outer diameter) that you may need to increase the hole diameter on some perfboards.

Specifications:

- Number of poles: 3

- Pin pitch: 3.5mm

- Fits 18 - 26 AWG wire

- Current rating: 5A @ 300V

- Insulation resistance: 5000Mohm/DC1000V
