Mega 2560 PRO Module (Type-C) - (AD61592)

Description:

This is an embedded version of Mega 2560 CH340G/ATmega2560 - compatible with the Arduino Mega 2560 board. Built on the Atmel ATmega2560 microcontroller and the CH340G USB-UART interface chip. The board has a compact size of 38 x 55mm. It is a good solution for making your final project on a solder proto-board.

This board has similar functionality to the Arduino Mega 2560. It is an embedded board, but just as stable, and uses the original ATmega2560 (16 MHz) chips.

The board uses the CH340G chip as a UART-USB converter. When working at a frequency of 12Mhz, it provides a stable data exchange result (you need to install drivers on the computer).

This Mega PRO 2560 connects to the computer via a Type-C cable (used for almost all Android smartphones). You can power the board via the connector or through pin headers. The voltage regulator (LDO) can handle incoming voltage from 6V to 9V (peak 18V) DC. Output current for 5V - approximately 800mA, for 3.3V - approximately 800mA (note that the higher the input voltage, the lower the output current). This will provide reliable power to most of your initial projects.

This board DOES NOT include a USB cable.

Note: This board comes with unsoldered pins!

Specifications:

- Microcontroller: ATmega2560

- Power Input: 7-9V (18V peak)

- Output Voltage: 5V @ 800 mA, 3.3V @ 800mA

- Digital I/O Pins: 54 (of which 15 provide PWM output)

- Analog Input: 16

- 4 UART bus

- Size (LxWxH): 55x39x6mm
