0.5A @ 125V SMD 1808 Ceramic Fuse - (AD58073)

Description:

These miniature fuses feature a multi-layer design and have the advantage of exposing more surface area to the glass-ceramic absorption material. When the fuse elements open, there is more material to vaporize the metals and absorb them, resulting in highly efficient arc extinguishing. The fuses help prevent costly damage and promote a safe environment for electronic and electrical devices.

Characteristics:

- Brand: Littelfuse

- Series: 451

- Body: Ceramic

- Ampere rating: 0.5A

- Maximum nominal voltage: 125V

- Package size: 1808 (6.10 x 2.69mm)

- Opening: very fast action (FF)

Data sheet
