MLX90614 - SparkFun IR Thermometer Evaluation Board [SEN-10740] - (AD53208)

Description:

This is an evaluation board for the MLX90614 IR thermometer. The sensor is connected to an ATmega328 running at 3.3V and an 8MHz STK500 (Arduino) bootloader. Code can be uploaded via the FTDI Basic interface and the Arduino environment.

The MLX9061 sensor is a high-precision, small-sized, single-zone IR thermometer with an optional SMBus (two-wire) or PWM interface. The ATMega328 comes with demo code that provides a temperature reading in degrees F at 38400 bps. You can use a 3.3V FTDI Basic to connect to the board.

This revision fixes the silkscreen error on the FTDI header. We've also added pull-up resistors to the I2C lines.

Characteristics:

• ATMega328 w/ 8MHz STK500 (Arduino) bootloader
• MLX90614 IR sensor, 3V version
• Power and status LEDs

Documents:

• Schematic
• Eagle Files
• Hookup Guide
• Datasheet (MLX90614)
• GitHub

Reference link
