[6 x 6mm] Latching Mini Tactile Push Button Switch DPDT - (AD51929)

Description:

This is a perfect option if you need an on/off button! These plastic buttons are a small, very sturdy PCB-mount latching switch. It's a DPDT with 6 pins spaced at 2mm, meaning it is NOT breadboard compatible. This button is perfect for basic on/off functions. These latching buttons support up to 0.1A and 30VDC. Sold individually!

Features:

- Size: 6x6mm

- Operating temperature: -40°C to +70°C

- Average load: 30VDC @ 0.1A

- Insulation resistance: 100 Mohm

- Contact resistance: 0.03 ohm

- ON state when pressed

- OFF state when pressed again
