74LS01 2-Input NAND Gate - (AD479)

Description:

The 74LS01 2-input NAND gate operates at a typical supply voltage of 5V, offering open-collector outputs that facilitate its integration into various circuits. Its design includes low-power Schottky diodes to improve switching speed and energy efficiency. It operates over a wide temperature range from -55°C to +125°C, ensuring reliable performance in demanding environments. Ideal for digital applications requiring high-speed NAND logic with thermal robustness.

Datasheet
