Gas Sensor Breakout Board - (AD4570)

Description:

Simple breakout for the MQ-3, MQ-4, and MQ-6 gas sensors. All you need is VCC to 5V, GND, and a resistor to an ADC—that's it.

Note: This is just the PCB.

Dimensions: 16.8mm diameter

Documents:

• Schematic
• Eagle Files
• Wiring Example
