JTaE-DC12V Relay SPDT 12V @ 30A - (AD35605)

Description:

DC power relays interrupt high-capacity DC loads and high-voltage DC circuits in a compact, quiet design. The switching and driving sections are gas-injected and hermetically sealed, allowing these compact relays to interrupt high-capacity loads. The sealed construction also requires no arc space, saving space and helping to ensure safe applications.

These are single-pole, double-throw (SPDT) protective relays. Use them to switch high-voltage and/or high-current devices. The coil of this relay is rated up to 12V, with a maximum switching voltage of 250VAC, 24VDC. The contacts are rated up to 30A (at 250VAC).

Contact Data:

- Contact: NO, NC

- Rated voltage: 250 VAC

- Maximum switching voltage: 250 VAC

- Rated current: 30 A. Limit continuous current: 30 A

- Limit breaking current: 30 A

- Contact material: AgCdO

Coil Data:

- Coil voltage range: 12 VDC

- Maximum coil power: 1.0 W

- Maximum coil temperature: 155 °C

- Coil insulation system according to UL Class F
