Blue LED - 3W to Aluminum PCB - (AD32506)

Description:

So much power and light in such a small package. This “cool” white 3 Watt PCB-less LED with an aluminum backing is sure to shed a lot of light on whatever project you add it to. These LEDs act like any other LED except these little guys require much more power while putting out light as intense as a thousand suns going supernova (this is an exaggeration, but you get the idea)!

Each LED needs an aluminum backed PCB to help with heat dissipation and outputs a warm white light. Also, each LED requires a forward voltage of 3.2-3.8V @ 750mA.

Note: We like to joke about supernovas and all that, but seriously, don't stare directly into the LED.

Features:

- Forward Voltage: 3.2-3.8V

- Forward Current: 750mA

- Viewing Angle: 125 ± 5 degrees

- Luminous Intensity: 160-200LM

- Color Temperature: 3000-3300K

Documents:

• Datasheet
• Product Video
