14 AWG TEMCo Magnet Wire [PER METER] - (AD11944)

Description:

Magnet wire is super useful and, when you need it, there's nothing else that will work. Whether you're winding a transformer or choke, creating your own motors, or just generally playing with electromagnetism, nothing beats this 14AWG enameled wire. Everyone has their own method for removing the enamel insulation to make a connection with this material, but a bit of abrasion with sandpaper or scraping with a hobby knife works well. If you have an open flame handy, you can also burn off the enamel, just be careful!

Specifications:

- 200°C Copper Magnet Wire

- TEMco MR-200

- Gauge: 14AWG

- Brand: TEMCo USA

- Solid Round Conductor (99.9% Pure)

- Insulation Temperature: 200°C

- Enamel Type: Polyurethane

- Double Enamel: Heavy Duty

- Average wire diameter: 1.7mm

- Color: Amber

- Sold by the METER

Applications:

Appliance motors, relays, clock coils, encapsulated coils, arts and crafts.
